The Turbo Guy
Joined
·
205 Posts
Discussion Starter #1 (Edited)
Joey's Mazderati

2012 Mazda 3 i Touring SkyActiv 2.0L 6AT




Powertrain
ECM tune by OV Tuning for 87 octane
JBR hot air intake
CorkSport intake air box shield, with colder ram air modification
MSDS SkyActiv exhaust manifold with ceramic coating
Custom exhaust system:
- Magnaflow 15127 catback system
- MagnaFlow 2.5” catalytic converter 51306 in place of second cat
- Vibrant Performance 2.5” Ultra Quiet Resonator 1141 in midpipe
Mishimoto universal 19-row oil cooler with 200*F thermostat
CorkSport oil catch can with drain valve
Mishimoto M14x1.5 magnetic oil drain plug
Flex Innovations grounding kit (unique routing)
Modified OEM engine mount with 60A polyurethane
CorkSport MazdaSpeed 3 transmission mount polyurethane insert
Hardrace rear engine mount
CorkSport exhaust hangers

Suspension - front MacPherson strut
Ground Control MazdaSpeed 3 coilover kit
Hyperco 250 lb/in springs, 8" length, 2.5" ID
Modified OEM front struts
GC bump stops
CorkSport front strut camber plates
Eibach spring bags to prevent dirt ingress
Whiteline Mazda 3 24mm front sway bar
CorkSport MazdaSpeed 3 front endlinks
SuperPro SPF3115K front lower control arm bushings
SuperPro SPF3370K rear lower control arm bushings (set to anti-lift)
Whiteline KCA405 bump steer kit

Suspension - rear multilink
Ground Control MazdaSpeed 3 coilover kit
Hyperco 400 lb/in springs, 7” length, 2.5” ID
Hyperco 25 lb/in helper springs with Eibach spacer
CorkSport Mazda 3 adjustable rear dampers
CorkSport Mazda 3 25 mm rear sway bar, set to soft
CorkSport Mazda 3 rear sway bar bushing mounts
OEM MazdaSpeed 3 rear endlinks
Eibach rear adjustable camber arms
Hardrace rear toe arms with stiffer rubber bushings

Suspension Tuning
Design: street touring - sporty yet comfortable daily driver that can handle the occasional twisties or HPDE
Camber: about -2.5*F / -2.0*R
Toe: 0 F / 0 R
Ride height: about 27.0"F/ 27.0”R ground to fender with 265/35/18 tires
Front dampers: n/a F and 8/15 R, clicks from full soft
Tire pressure: 35 F / 36 R psig cold
Steer characteristics: TBD

Chassis bracing
CorkSport front strut tower brace (modified holes to access strut top)
Ultra Racing UR-FD3-1961 fender braces
CorkSport rear chassis brace
GT Spec front subframe ladder brace, GTS-SUS-1135
GT Spec front subframe H brace, GTS-SUS-1190
GT Spec mid chassis brace, GTS-SUS-1158
GT Spec rear toe arm brace, GTS-SUS-1126
AutoExe front lower control arm bar, MBL4B00
AutoExe rear seat floor brace, MBL450

Brakes
OEM Mazdaspeed 3 front brake calipers and brackets
StopTech Sport (formerly Street Performance) Mazdaspeed 3 front brake pads
KNS Brakes titanium front brake pad shims (modified to fit)
Centric 125 Series Mazdaspeed 3 front brake rotors
OEM Mazda 5 rear brake caliper brackets (with OEM Mazda 3 calipers)
StopTech Sport (formerly Street Performance) Mazda 3 rear brake pads
Centric 120 Series Mazda 5 rear brake rotors
Goodridge stainless steel brake lines
DOT 4 brake fluid

Summer wheels and tires
TR Motorsports MT1 grey 18x9.5 +45 wheels
Michelin Pilot Super Sport 265/35/18 max summer tires
Front Eibach 10 mm wheel spacer kit with ~10 mm extended studs
Rear 3 mm wheel spacers
TireRack 79.5 mm to 67.1 mm hub centric rings
McGard M12x1.5 spline lug nuts, black

Winter wheels and tires
XXR 530 hyper silver 17x8.25 +35 wheels
Bridgestone Blizzak WS70 235/45/17 studless winter tires
Front Eibach 10 mm wheel spacer kit with ~10 mm extended studs
67.1 mm hub centric rings, TPMS sensors, XXR center caps
McGard M12x1.5 spline lug nuts, black

Interior
2008.5-2009 MazdaSpeed 3 front seats (GT trim, modified bracket to fit Gen2)
Schroth quickfit 4-point ASM racing harnesses, driver and passenger, Subaru STI model (modified one buckle)
AutoExe leather steering wheel, part MBL1370-03
WC Lathe Werks custom shift knob
WeatherTech FloorLiner floor mats
Dynamat Xtreme sound deadener (doors, trunk, hatch & privacy screen, hood)
Dynamat hoodliner sound deadener
UltraGauge EM Plus with horizontal mount
Mazda 3 aluminum pedal covers
Mazda 3 aluminum door scuff plates
CorkSport LED light kit
CorkSport Mazda performance guide book
OEM Mazda 3 trunk carpet
OEM Mazda 3 trunk plastic mat

Exterior
Solar Gard Ultra Performance 75 window tint
TheRetrofitSource Mazda3 Retro-Quik lens projectors (Morimoto Mini D2S 2.0)
Morimoto HID low beam kit: 35W ballasts, 5500K bulbs, HD H11 relay
- Added rubber washers, which press against the OEM rubber seal and attach to the igniters with RTV gasket maker
- Ballasts mounted under the headlights with industrial Velcro
Philips HIR 9011 high beam halogen lights, trimmed to fit OEM 9005 fitment
Painted headlight shrouds black
Diode Dynamics LED back up lights, XP80 model
Torque Solutions short antenna (reduced signal, occasionally used)
CorkSport hood dampers
Subaru STI 06-07 polyurethane front lip (modified to fit)
OEM JDM window visors, part number BBW5-V4-530
Rally Armor UR mud flaps, black urethane with silver logo, rear flaps trimmed
OEM Mazda 3 rear bumper protector

Other
RaceQuip SportMod SA-2010 helmet
VP Race Fuels 5-gallon gasoline containers
Small funnel with 5/8" OD vinyl tubing attached in order to fill the transmission fluid without removing the intake air filter and box



·
The Turbo Guy
Joined
·
205 Posts
Discussion Starter #2 (Edited)
Front view
Road Magnet 1.75” front progressive springs
CorkSport front strut camber plates
Enkei RPF1 silver 17x9 +45 wheels
Continental ExtremeContact DW 255/40/17 max summer tires
3mm hub centric front wheel spacers
~2.5* camber and ~25.5" ground to fender ride height


Front angled view
Road Magnet 1.75” front progressive springs
CorkSport front strut camber plates
Road Magnet 1.25” rear progressive springs
Enkei RPF1 silver 17x9 +45 wheels
Continental ExtremeContact DW 255/40/17 max summer tires
3mm hub centric front wheel spacers
~ 25.5”F / 25.8”R ground to fender ride height
~ 2.5*F / 2.1*R camber


Side view
Road Magnet 1.75” front progressive springs
CorkSport front strut camber plates
Road Magnet 1.25” rear progressive springs
Enkei RPF1 silver 17x9 +45 wheels
Continental ExtremeContact DW 255/40/17 max summer tires
Rally Armor UR mud flaps, black urethane with silver logo, rear flaps trimmed
~ 25.5”F / 25.8”R ground to fender ride height


Rear angled view
Road Magnet 1.25” rear progressive springs
Enkei RPF1 silver 17x9 +45 wheels
Continental ExtremeContact DW 255/40/17 max summer tires
Rally Armor UR mud flaps, black urethane with silver logo, rear flaps trimmed
~25.8” ground to fender ride height
OEM Mazda 3 rear bumper protector


The garage


Enkei RPF1 silver 17x9 +45 wheels
Continental ExtremeContact DW 255/40/17 max summer tires
3mm hub centric front wheel spacers
McGard M12x1.5 spline lug nuts, black
Rally Armor UR mud flaps, black urethane with silver logo
MazdaSpeed 3 brake calipers and rotors
~25.5" ground to fender ride height


Enkei RPF1 silver 17x9 +45 wheels
Continental ExtremeContact DW 255/40/17 max summer tires
McGard M12x1.5 spline lug nuts, black
Rally Armor UR mud flaps, black urethane with silver logo, rear flaps trimmed
Mazda 5 brake calipers and rotors
~25.8" ground to fender ride height


XXR 530 hyper silver 17x8.25 +35 wheels
Bridgestone Blizzak WS70 235/45/17 studless winter tires
McGard M12x1.5 spline lug nuts, black
Rally Armor UR mud flaps, black urethane with silver logo
MazdaSpeed 3 brake calipers and rotors
~25.5" ground to fender ride height


XXR 530 hyper silver 17x8.25 +35 wheels
Bridgestone Blizzak WS70 235/45/17 studless winter tires
McGard M12x1.5 spline lug nuts, black
Rally Armor UR mud flaps, black urethane with silver logo, rear flaps trimmed
Mazda 5 brake calipers and rotors
~25.8" ground to fender ride height


CorkSport front strut tower brace
CorkSport short ram intake
CorkSport intake air box shield
CorkSport hood dampers


CorkSport short ram intake
CorkSport intake air box shield
CorkSport oil catch can with drain valve


CorkSport front strut tower brace (access hole enlarged for adjustable dampers)
CorkSport Mazda 3 adjustable front struts
CorkSport front strut camber plates


CorkSport Mazda 3 adjustable front struts
CorkSport MazdaSpeed 3 28.5mm front sway bar
CorkSport MazdaSpeed 3 front endlinks
Whiteline KCA405 bump steer kit
Enkei RPF1 silver 17x9 +45 wheels
Continental ExtremeContact DW 255/40/17 max summer tires
3mm hub centric front wheel spacers


Ultra Racing UR-FD3-1961 fender braces
Required pulling the fenders in order to drill the forward mounting holes


SuperPro SPF3115K front lower control arm bushings
SuperPro SPF3370K rear lower control arm bushings (set to anti-lift)
GT Spec front subframe ladder brace, GTS-SUS-1135
GT Spec front subframe H brace, GTS-SUS-1190


SuperPro SPF3370K rear lower control arm bushings (set to anti-lift)
GT Spec front subframe ladder brace, GTS-SUS-1135
GT Spec front subframe H brace, GTS-SUS-1190


SuperPro SPF3370K rear lower control arm bushings (set to anti-lift)
GT Spec front subframe ladder brace, GTS-SUS-1135
GT Spec front subframe H brace, GTS-SUS-1190


Front lower control arm angle with ~25.5" ground to fender ride height
Road Magnet 1.75” front progressive springs
CorkSport front strut camber plates
Whiteline KCA405 bump steer kit
CorkSport oil catch can with drain valve
Continental ExtremeContact DW 255/40/17 max summer tires


CorkSport oil catch can with drain valve


5.25" front frame rail height results in the control arm angle shown in the picture above


Road Magnet 1.25” rear progressive springs
CorkSport Mazda 3 adjustable rear dampers
~25.8" ground to fender ride height


CorkSport Mazda 3 adjustable rear dampers


Road Magnet 1.25” rear progressive springs
CorkSport exhaust hangers


JBR 32 mm 0.250”-wall hollow rear sway bar
JBR rear sway bar bushing mounts
GT Spec mid chassis brace, GTS-SUS-1158
GT Spec rear toe arm brace, GTS-SUS-1126


JBR 32 mm 0.250”-wall hollow rear sway bar, set to medium
JBR rear sway bar bushing mounts
OEM MazdaSpeed 3 rear endlinks
GT Spec rear toe arm brace, GTS-SUS-1126


UltraGauge EM Plus with horizontal mount


Mazda 3 aluminum pedal covers


Dynamat Xtreme sound deadener in the trunk


Dynamat Xtreme sound deadener in the doors


Dynamat Xtreme sound deadener on the hood with Dynamat Hoodliner on top



Flex Innovations grounding kit
throttle body --> negative battery terminal --> engine block --> engine beauty cover bracket --> bracket --> chassis ground



Mazda 3 aluminum door scuff plates



·
Registered
Joined
·
5,839 Posts
I think you need to add an exhaust. Mazdaspeed 3 exhaust to be exact. I can provide if needed. ;)


·
Registered
Joined
·
5,636 Posts
That's a heck of a mod list. Congrats.


·
The Turbo Guy
Joined
·
205 Posts
Discussion Starter #7
I think you need to add an exhaust. Mazdaspeed 3 exhaust to be exact. I can provide if needed. ;)
I believe that is a dual tip muffler, right? I don't think it would play nice with my single exit bumper. I've thought about an exhaust, but it is nice to have something quiet while cruising around town. The Subaru is straight piped with an external wastegate dump so it is on the other side of the spectrum.

Nice job. That's a lot of good work you've put into the car. Now hurry up and get some good pics. Right thumb!
That's a heck of a mod list. Congrats.
Nice mods list!............and STI!
Thanks, everyone. I tried to clean the car and get some pictures for post #1.


·
Registered
Joined
·
752 Posts
soo much bracing! Im jealous


·
Aspiring Mad Scientist
Joined
·
1,716 Posts
Didn't you just quip that I had spent a lot of money on my car? :Na_Na_Na_Na 1:


·
The Turbo Guy
Joined
·
205 Posts
Discussion Starter #11
I updated post #1 with more pictures.
Didn't you just quip that I had spent a lot of money on my car? :Na_Na_Na_Na 1:
Only because you are a student, which typically means time and money are limited.
Where did you come from?

Nice build and mods....
Thanks. I come from the middle of the corn fields, part way between the East Coast and California crews.


·
Aspiring Mad Scientist
Joined
·
1,716 Posts
Only because you are a student, which typically means time and money are limited.
I've never felt so patronized! lol. I'm just a student for one year. Saved up enough from working to pay for everything, debt-free, etc. as long as I don't go completely nuts. I certainly couldn't justify buy all the things you have on your car, but I can MacGyver and design my own bits to work. :)


·
The Turbo Guy
Joined
·
205 Posts
Discussion Starter #14
I've never felt so patronized! lol. I'm just a student for one year. Saved up enough from working to pay for everything, debt-free, etc. as long as I don't go completely nuts. I certainly couldn't justify buy all the things you have on your car, but I can MacGyver and design my own bits to work. :)
Good deal, one-n-done. I only patronize because I admire your dedication and resourcefulness, not to mention the stones needed to push 285 extreme summer tires on the street. With my luck, I would round a blind corner and rear end someone, especially since the Mazda3 likes to come into a corner hotter than the space shuttle entering atmosphere and delicately trail brake all the way past the apex. My car is neutral while coasting or light trail braking, but it can easily scoot the rear end out with enough braking force.

All the bracing AND the jbr comp bar must be bonkers! :Racing 1:

Love the build!
Thanks. The 1.25" competition 0.250"-wall rear sway bar was needed to balance the 28.5 mm solid front sway bar. Not many people stiffen the front sway bar, and I can see why.


·
Aspiring Mad Scientist
Joined
·
1,716 Posts
Me stones may have gotten me in trouble once or twice lol... Not proud.

Are you getting any one-wheel-peel with the front bar in place? I have not heard of anyone who has been able to use it in a competition setting, even with a big rear sway.


·
The Turbo Guy
Joined
·
205 Posts
Discussion Starter #16
Are you getting any one-wheel-peel with the front bar in place? I have not heard of anyone who has been able to use it in a competition setting, even with a big rear sway.
Yes and no.

No, because I don't try to put the power down during >95% of corners.
- Enter corner fast
- Brake late and continue trail braking past the apex
- Wait for it
- Get back on the throttle when the steering wheel is nearly straight again
- Regain speed for the next corner

Yes, because a FWD car wants to light up the inside tire if trying to put power down immediately upon corner exit or throughout the corner. An example on the street is an exchange ramp from one highway to another; if maintaining a constant speed while trying to take the corner as fast as possible, it wants to spin the inside tire, but I'm still going 30+ mph over the suggested speed so it doesn't reeeaaally need to be more capable.

If you can't accept the 'wait for it' step, then you have to soften the front sway bar and use stiffer springs for roll control. I would argue my setup is more comfortable than a car with stiff springs yet it still manages to be fun and capable on the street; mine it not meant to be a track or autox dual-duty car.


·
Aspiring Mad Scientist
Joined
·
1,716 Posts
I've been playing with mine for a while to see how early I can get ON the power as that's what generates the lowest lap/sector times. Streets of Willow was killing me when I had to wait to hit the throttle. I've been slowly retooling the setup -- stiffer rear springs, more front rake, aero -- to be accept more power 'cause it only gets worse above 200hp.


·
The Turbo Guy
Joined
·
205 Posts
Discussion Starter #18 (Edited)
I installed the Ultra Racing UR-FD3-1961 fender braces today. I haven't driven yet though. This was a worthwhile mod on my Subaru (even though Subaru provided flimsy OEM brackets) so I figured I'd try it on the Mazda3, which required importing the braces from Malaysia. I thought they'd bolt on if I just pulled the fender liner, but that was not the case.

There are no holes for the forward mounting location. I had to pull the fender so I could drill holes.


Drilled 1/4" holes with the bracket mocked up, then tapped M8x1.25 so the bolts were held captive as I tightened the nuts


I've been playing with mine for a while to see how early I can get ON the power as that's what generates the lowest lap/sector times. Streets of Willow was killing me when I had to wait to hit the throttle. I've been slowly retooling the setup -- stiffer rear springs, more front rake, aero -- to be accept more power 'cause it only gets worse above 200hp.
Yeah, I understand. My biggest gripe on the street is that when I do get back on the power it's 150 lb-ft. :sleeping:


·
The Turbo Guy
Joined
·
205 Posts
Discussion Starter #20
Holy taught!! I like where your mod mind is at. Well done!
Thanks.

I think the front end feels firmer, but my results are a bit confounded (installed upgraded brakes and drove the STI before the afterward test drive). I figure anyone who wants to source the fender braces and install them will already know they want it.

The upgraded brakes feel great when stopping. I was able to have a friend help me flush the brake fluid so I didn't dink around with the caliper paint. While the car now stops like a sports car, it was not without some tradeoffs due to the increased weight and inertia - slightly slower to accelerate, slightly longer distance to coast to a stop, slightly less agile since each corner feels heavier, and a little different feel over bumps.

The better front caliper design also helped eliminate this intermittent brake squeal I had up front. I felt the pad was lightly touching the rotor after releasing the brakes, and I tried everything to stop it: re-bedded the brakes, lubricated the slider pins, added anti-squeal on the back of the pads, and even visited the stealership.

It is now officially cold so I switched over to the winter wheels and tires. I also installed the UltraGauge and aluminum pedal covers. Pictures added to post #2.

1 - 20 of 144 Posts
Top
